Product: GSM gateways |
Model name:TLD SX01G-8ways |
|
Place of Origin:
China |
Brand Name: TELESTAR |
|
Quality/Safety Certifications:
CCC,CE |
Price Terms:
FOB ShenZhen |
|
Minimum Order:
1 units |
Payment Terms:
T/T in advance |
|
Delivery Lead Time:
3 days |
Supply Ability:
2,000 units/month |
Features:
-
Providing 900mhz and 1800mhz GSM
connectivity. 850mhz/1900mhz optional
-
watch Dog function.
It will auto reset if it find the device have
problems. So our gsm gateway cal working fine
with a long time donot need to power off and
power on. It never been dead status.
-
Auto or manual IMEI changed (optin)
You can set difference IMEI for every SIM
card or set the device make a random IMEI for
erery sim cards.
-
Auto Forward the Message received to your
mobile(optin)
The GSM operator will send a message to the SIM
if they find your talking bill is too large,
They will lock your SIM if you donot reply his
message. So this function can help you reply the
message check of gsm operator. It is useful
functions
-
Standard FXS (RJ11) interface
same as a PSTN.Compatible to PABX,VOIP
gateway, IP PBX, Call back system, cord
phone, Voice system, and etc.
-
Very clear voice. No echo and noise.
-
Delay reversal polarith or accuracy
Polarity reversal signal for metering
-
Simple to install/easy to maintain
-
Allow PIN code entering and reciprocal
phone-card lock
-
Provide optimized circuit directly
connecting the exchange device for
extensions
-
Signal is strong with 3.5dBi gain antenna
-
Standard parameters of Dialing tone and
busy tone
-
Call back function
-
Provide auto add Prefix number function
-
Forbid incoming call.
-
DTMF Dialing ,
Support 2nd Stage Dialing
-
Display Incoming caller ID. With dtmf or fsk
·
Hide calling out number(CLIR).
·
Set rapid reaction when detecting busy signal
·
Can set dial speed, quck dial and slow
dial.(dial delay time)
·
Chearly show Working state and signal indicator
with perfect quality LED
·
Remote Update the program(option)
You can connect to a cable to a computer, run a
software to update the software remote
Specifications:
-
Air interface standard: GSM 900/1800 MHz
Phase 2+
-
Frequency ranges:
GSM900:
§
Transmit: 890~915MHz; Receive: 935~960MHz
GSM1800:
§
Transmit: 1710~1785MHz; Receive: 1805~1880MHz
-
Channel space: 200KHz
-
Sensitivity: -104dB
-
Peak power consumption: 16W
·
Phone interface：supply
RJ-11 Phone Interface
·
Hanging voltage:
48V.
Dialing tone Frequency：450Hz
-
Operating environment requirements:
-
Temperature: 0°C - +40°C
-
Relative humidity: 45% - 90%
-
Connectors: SMA antenna connector
-
Atmospheric pressure: 86~106Pka
-
Power consumption: static≤
200 mA, emission≤ 4000 mA
-
Antenna: Gain: 3.5dB (all directional) 12
dB(Certain/selection)
-
Power supply:
-
AC220V±10%
47-54Hz AC110V/60Hz(
optional)
-
DC12V
(
optional)
Packing:
-
Product dimension: L 440x W260 x H48 mm
(1U)
-
Carton dimension: L 495x W325 x H110
mm 1pcs/carton
-
G.W: 3.6Kg
