SX02W01



　

Technique Parameters:

 The main features:

1. MT6737T 4-core 1.45G CPU is used.

2.1G/2G LPDDR3 733MHz RAM. (1G comes standard)

3. 8G/16G/32G EMMC ROM. (Standard 8G)

4. Expandable memory card

5. Bluetooth 4.0 support

6. Supports 2.4G/5GHz 802.11 a/b/g/n.

7. Support GPS.

8. Support 7 inch 1024X600 resolution LCD.

9. Support 13 million pixel camera, (standard 5 million)

10. Support the expansion of various types of SENSOR.

11. Support OTG.

12. Hot-swappable

13. Power supply: 5V1A

RF band: optional

1. GSM: 850/900/1800

2. WCDMA: 900/2100 (optional 850/2100)

3. TD-SCDMA: B34/B39

4. FDD_LTE: B1, B3, B7, B20

5. TDD_LTE: B38, B39, B40, B41

6. CDMA2000: BC0

Audio:

1. The audio sampling rate is 8KHz – 192kHz.

2. Audio sampling format: 8/16/24bit, mono/stereo

data transmission:

1.LTE: 150Mbps DL, 50Mbps UL.

2. WCDMA: 42.2M DL, 11.5M UL.

3. TD-SCDMA: 2.8M DL, 2.2M UL.

 4. GSM/GPRS: 85.6K DL, 85.6K UL.

 5.CDMA2000: 3.1M for forward link 1.8M for reverse link.

Packing information:

20pcs/carton

GW:  20.5/carton

Carton Size:  61.5*49*42CM/carton

Welcome OEM OR ODM.

Please contact us in:

skype wdg838@hotmail

Email: 649039046@qq.com

WhatApp: +8613925210958
